invisible universe

invisible universe

About 380,000 years after the Big Bang, our still relatively young universe reached an important milestone. It was still very hot, but just cool enough for neutral atoms to form from the electrons, neutrons and protons that had been flying around freely until then. The light particles, photons, which had been created and absorbed over and over again in the time before, could suddenly move freely - all of a sudden the universe became transparent. In the reverse conclusion this also means that before this time no light could escape from the "hot mush". Telescopes are of no use to us here - science had to develop other devices to track down the early universe: Particle accelerators.

Cosmic background radiation

The “view through the window” shows the distribution of cosmic background radiation. It is a remnant of the Big Bang and the oldest light in the universe. Its properties tell us more about the state of the universe when it "suddenly" became transparent to this radiation about 380,000 years after the Big Bang. At this time, the universe was almost perfectly homogenous – a little bit like the surface of a lake on a windless day. The bright and dark areas show the tiny variations in density of this early universe. To make them visible the colour contrast has been enhanced by a factor of more than 10,000. These variations were the basis for the formation of our stars and galaxies today. Therefore, cosmic background radiation provides direct evidence that the Big Bang theory is correct.

Cosmic background radiation can be used to calculate all the major characteristics of our universe, such as its age, density, and development over time.

The colored image shows a large oval against a black background. There are many small spots in orange, green and dark blue.
Damien P. George
Image: Planck space telescope

The universe’s first light

Photons (particles of light) could not cross the young, very hot universe unhindered. On their journeys they collided with electrically charged free protons and electrons. Only once the universe had cooled down to 2,700 degrees was it possible for neutral atoms to form. This meant that photons could pass unobstructed and travel through the universe. These photons form the cosmic background radiation, which we can still observe today.

In front of a dark wall we see a large box-shaped machine with a window in the middle. Through this window you can see how small white balls - illuminated red from above - fall down. In the upper area they jump back and forth a lot, while in the lower area they can fall freely.
C. Helge Mundt
Loan from: Institut für Hochenergiephysik (HEPHY) der ÖAW

Spark chamber

A black box stands in front of a blue background. If you look closely, you can see a flash running through the box from top to bottom.
Leihgabe/loan from: DESY Zeuthen, Foto: C. Helge Mundt
The flashes you see and hear here are real particles from space, made visible by our spark chamber. These particles are also zipping through our bodies all the time, we just don't notice them. We are permanently exposed to a small but measurable level of radiation in the form of cosmic particles. Part of this is due to highly charged particles from space colliding with atoms and molecules of our atmosphere, thereby generating a particle shower. Of these particles generated, only muons are able to reach Earth’s surface. These electrically charged particles leave behind, albeit very briefly, an invisible trace of charged gas particles. Spark chambers make it possible to see this ionisation trail. Try putting your hand in the chamber to see particles just passing through. This is something that happens all the time!
The colored illustration shows the earth's surface in brown below and the layers of air in our atmosphere from light to dark blue above. On the left, you can see the layers of the atmosphere labeled as well as an altitude scale in kilometers. From the top right, a white arrow points slightly sloped downward (primary cosmic rays). At the level of the mesosphere, this arrow begins to branch out like lightning. These branches are green, red and wavy black lines pointing down to the earth's surface. Each of these lines is labeled with a letter; the explanation which particle which letter means is written underneath in white. In the center of the illustration there are little pictures in white for comparison: how high Mount Everest is, the altitude of an airplane and a weather balloon, from which height Felix Baumgartner jumped and how high above the earth satellites circle.
DESY Zeuthen

Cloud chamber

This cloud chamber makes invisible charged particles visible. These particles constantly surround us. The chamber is filled with a supersaturated air-alcohol mixture (ethanol vapour). When a charged particle passes through the gas, it ionises individual atoms of the gas. Like a condensation trail of a plane in the sky, the flight path of the charged particle becomes visible as a condensation trail because the ions become condensation nuclei on which the saturated alcohol vapour can deposit and leave visible traces.

A square space can be seen through a glass plate. Inside the square, a short thick line and several long thin lines can be seen.
Leihgabe/loan from: DESY, Foto: C. Helge Mundt
By the way, different particles leave different traces: if you keep looking at the vapour you can observe a whole series of different traces.

Jan Köchermann

Frassek's Space Collector / film, 2018
Frassek's Cellar, 2018
Frassek's Space Collector / model, 2018

In the 1960s, the forgotten particle physicist Hubertus M. Frassek invented an automobile with a funnel-shaped collector as a measuring device to prove the existence of tiny black holes. Jan Köchermann let his reconstruction of Frassek's Space Collector first search for minute black holes on the DESY premises in Hamburg in 2017: the starting point of an artistic research project that has manifested itself in multiple forms. In blurred sepia tones, Köchermann's Super 8 film follows the eccentric scientist on his futuristic mission in the funnel vehicle. A peephole installation, in turn, provides a view of Frassek's Cellar, in the depths of which a dark vortex leads into nothingness like a black hole. As a miniature replica, the Space Collector makes reference to the imagination-driven vehicles of bold visions that provide the decisive impetus for scientific knowledge. Köchermann's spatial interventions and constructions are models of an expanded perception. They give shape to the inconceivable and make the invisible palpable—extending way beyond Frassek's Space Collector.

In front of a dark blue wall we can see three objects: there is a white box hanging on the far left with a small hole to look into. Next to it is a small glass case containing a model car with a large funnel on the roof. On the right there is an old-fashioned TV that is currently showing a black and white picture of the same car with a funnel on the roof.
C. Helge Mundt
Inside the white box we see a narrow metal platform with railings and a staircase leading down. However, the stairs are
C. Helge Mundt
View into the "cellar", which can be seen as a white box on the left in the previous picture

App "Trapped in Gravity"

Why are black holes black? What are gravitational waves? And what can we learn about the universe by observing gravitational waves? The game app Trapped in Gravity provides playful insights into the physics behind mass, gravitational forces and black holes. The game was developed by researchers from the Cluster of Excellence Quantum Universe.

Read more or download the game

Mysterious dark matter

Around 26 percent of the universe consists of a form of matter that we have never seen directly.

Unlike visible matter, this so-called dark matter can neither emit nor absorb light and is therefore invisible to us. So far, it can only be detected indirectly through its gravitational effect on visible matter.

Researchers suspect that dark matter was not always "invisible". Fractions of a second after the Big Bang – when the universe was filled with a hot plasma – it began to interact actively with the matter we know. Collisions of particles of matter known to us created new particles of dark matter. As the universe continued to cool, a remnant of dark matter remained.

The colored image shows three cubes framed in red. The cube on the far left is quite uniformly filled by a bluish-white mist. Small yellow dots are scattered in there as if by chance. In the cube on the far right, the bluish fog forms strands that form a net. Yellow dots collect along these strands. The middle cube is filled with a middle ground between evenly distributed fog and clearly recognizable strands.
mpa, Garching
Distribution of dark matter (simulation): Dark matter (blue) creates structure in the universe. The arrangement of stars and galaxies (yellow) follows the distribution of dark matter.

Dark Matter Simulator

Would you like to go on a little scavenger hunt for dark matter? Maybe you can figure out where additional mass is hiding by observing the motion of little test particles.

Dark matter halos

In the outer areas of spiral galaxies, stars spin around the centre of the galaxy at such a speed that according to the laws of physics the galaxies should disintegrate. It is thought that they survive because they are embedded in a mysterious type of matter which holds them together. This halo of dark matter can be calculated by observing the movement of the stars.

This photo shows a monitor with a spiral galaxy in the center. Additionally, a diagram is plotted ontop of this galaxy, which shows the rotation speed in relation to the distance to the center. At the bottom of the screen a slider is shown, with which the proportion of dark matter in the galaxy can be changed.
C. Helge Mundt
Have a go yourself. Change the percentage of dark matter and watch how the orbital speed of the stars changes.

Into the invisible

You can see a curtain made of silver tinsel. There is a red and a yellow stripe stuck to the floor and a red arrow pointing towards the curtain.
C. Helge Mundt
Come on through to the other side – if you dare! Behind this curtain begins the universe that we can no longer explore with telescopes. When the universe was younger than 380,000 years, it was so hot and radiated so strongly that our access to it is blocked as if by a wall of light. We can only explore this era with the help of particle accelerators.
